What kind of electric meter is good for industrial parks? Tips for selecting electric meters in industrial parks
Publish Time: Author: Site Editor Visit: 7
Small scale park (current ≤ 100A)
When there are few electrical devices, priority should be given to using a first level precision 380V three-phase smart electric meter, which has time-sharing metering and loss monitoring functions and is suitable for scenarios involving electric motors. If basic metering is the main approach, directly connecting to an electric meter can meet the demand, and the cost per meter is 40% lower than that of a transformer type.
Large and medium-sized industrial parks (current>100A)
It needs to be equipped with a current transformer connected electric meter, with an accuracy level of not less than 0.5S. suitable for multi device intensive scenarios. For precision manufacturing enterprises, a 0.2S level electric meter can control the measurement error within 0.5%. Although the cost is 30% higher, it can avoid electricity disputes and energy consumption misjudgments.
2、 Tightly adhere to functional requirements and match scene characteristics
Basic Function Bottom Line
All parks must come standard with time-sharing metering, data storage, and communication functions. Parks containing high-power equipment (such as injection molding machines) must select a three-phase multifunction meter that can monitor parameters such as power factor and harmonics.
Advanced feature selection
Distributed workshop: prioritize NBIoT wireless meters, no wiring required, wide signal coverage;
High energy consuming enterprises: Electricity meters with demand monitoring function can optimize peak electricity consumption, and a certain electronics factory can save 12% on electricity bills this year;
Multi tenant park: Rail mounted electricity meters are easy to install densely and support loop metering and electricity cost sharing.
3、 Anchoring energy consumption management and bridging the data loop
Communication scheme adaptation
The main line uses RS-485 wired communication to ensure stability, and the branch circuit uses LoRa wireless solution to reduce the difficulty of transformation. The hybrid solution can achieve 99.9% signal coverage. Be sure to choose a model that supports standard protocols such as Modbus RTU, MQTT, etc., to avoid blocking the integration with energy management systems.
Remote control capability
The smart meter with relay can achieve automatic power-off and emergency cut-off for overdue payments, and the fault response efficiency has been improved by 60% after application in a chemical industrial park. Models that support remote parameter distribution and firmware upgrades can reduce 80% of on-site operation and maintenance workload.
4、 Practical selection guide for avoiding pitfalls
Environmental adaptation: The workshop needs to select an industrial grade electric meter with a protection level of IP54 or above and a working temperature of -25 ℃~70 ℃. The corrosive scenario should be upgraded to IP65;
Cost accounting: The initial investment in smart meters is 2-3 times that of traditional meters, but it can save over 300000 yuan in labor and energy costs in 5 years.
